DEWATERING SYSTEMS
Main benefits of using our systems:
1. Wide range of dewatering / TSS treatment capabilities
2. Designed for optimum treatment load is <0.5 (5000NTU) but may be effective as high as 2.0% solids or 20000 NTU
3. 2–6-week product life
4. Stainless steel construction
5. Replaceable stainless steel cartridges
6. Easily portable
7. Zero carbon footprint*
8. Treat and pump at the same time
9. Reduces metals, phosphorus, TSS, and other contaminants
FEATURES
 GFR 1000 |  GFR 300 |  GFR 100 |
|
| Flow rates for optimum treatment | 500 -750 GPM | 250-350 GPM | 100-150 GPM |
| Maximum flow rate | 1000 GPM | 300 GPM | 100 GPM |
| Dimensions | 137” x 16” | 71” x 16” | 24”x 48”x 48” |
| Weight ( without product installed ) | 500 lbs | 350 lbs | 500 lbs |
| inflow & Outflow Connections | 6” NPT | 4” NPT | 2” NPT |
| Cartridges Needed | 6 | 3 | 2 |
| Product Needed | Gel Flocculant Slabs | Gel Flocculant Slabs or Blocks | Gel Flocculant Slabs |
EQUIPMENT ACCESSORIES
SILT COLLECTION MATS ∙ STAINLESS STEEL CANISTERS TREATED JUTE CURTAINS ∙ FLOCCULANTS ∙ & MORE
Silt Collection Mats, Treated Jute for Filtration, Polishing Curtains, Ultrabind, Soil Lynx.
GEL FLOC
Clearflow has eliminated the need for the high-priced traditional flocculation system with Gel Flocculants. Simply install the gel block flocculant in situ. Reduce TSS, metals, phosphorous, arsenic plus more.
Available Forms
Gel Block Slab
Applications
Gravity Flow Pumped Flow
GFR 1000
This system is a flow-through reactor engineered to release Clearflow flocculant into the water. The he GFR - Gel Flocculant Reactor accelerates Gel Floc release; this enables treatment of higher flow rates in a smaller footprint.
Available Flow Rates
1000 USGPM
Applications
Flow Rates
TREATED JUTE
An erosion inhibitor on steeper slopes, reducing the potential for surface erosion. A screening process, prevents fine particulates from entering the stream and collecting those particulates already in the stream. As a final polishing agent, collect the fines still in suspension after primary treatment.
Specification
100ft x 3 ft ASTM Tested
Applications
Slopes
Channels
Hydroseeding
Water Bodies
GFR 300
This system is a flow-through reactor engineered to release Clearflow flocculant into the water. The GFR - Gel Flocculant Reactor accelerates Gel Floc release; this enables treatment of higher flow rates in a smaller footprint.
Available Flow Rates
300 USGPM
Applications
Flow Rates
